igubal split four-hole flange bearing – for quick installation and bearing replacement
The split igubal two hole flange bearings and spherical insert bearings offer an innovative assembly method that leads to a reduction in downtimes. Depending on accessibility, the replacement of one-piece bearings after wear can involve considerable conversion work. The split solutions from igubal eliminate this effort. Users can assemble and dismantle the bearings directly on the shaft without having to remove other machine parts.
The igubal two hole flange bearings with spherical insert bearing are a reliable and flexible solution for many industrial applications and impress with their strong design and excellent performance.
The housing is made of the impact-resistant polymer igumid G, which can withstand temperatures from -40°C to +120°C (short-term up to 180°C). The spherical insert bearing with integrated solid lubricants makes a maintenance-free dry operation possible, replacing permanently external lubrication and offering ecological and economic benefits.
More information about our spherical insert bearing:
Injection-moulded iglidur J3: -50°C to +90°C, short-term +120°C
machined iglidur J3: -50°C to +90°C, short-term +120°C
