drylin® WWC Monocarro

Fast and easy installation
No alignment
Robust, hard-anodised aluminium
Different installation sizes

Diseño: Cuadrado
Elemento de material deslizante: iglidur® J
Material: Aluminio

Descripción del producto

Easy installation, no alignment
With the WWC mono-slide carriage the easy assembly of the drylin W linear carriages is made even easier. No individual pillow blocks due to anodised aluminium carriages.

Tech up:

Extremely fast assembly of drylin® W linear carriage on drylin® W double rails
Monobloc made of aluminium for robust handling
Suitable for drylin® W profile rail WSQ-06-60
Sliding elements made from iglidur® J for long-lasting operation
In three lengths, available ready-to-install: 60/80/100mm

Cost down:

Save installation time with a ready-to-install design
No mounting or alignment
Save storage space - one component instead of nine (for standard linear carriages)
Reduced design effort with PDF and CAD file available in the online shop

Proof:

12% lower installation height than standard
Corrosion-resistant thanks to clear anodising
Tested: WWC carriage, installation size 06, load 80N, acceleration 3m/s², rail length 2,000mm, running performance 5,000km or 2.5 million double strokes of 1,000mm each

Sustainability:

Lubrication-free operation
Maintenance-free due to self-lubricating high-performance polymers from igus®
Lightweight components such as plastic and aluminium
